ISHAKO Diamond Series Controller
Product Support
Product Details
Specifications:
| Product Name | Wireless Controller |
|---|---|
| Support System | PS4/Slim/Pro, Windows (7/8.1/10/11), PS3, iOS/Android Devices |
| Battery Capacity | 600mAh |
| Working hours | 5-8 Hours |
| Charging Voltage/Current | DC 5V/250mA |
| Operating Temperature | 5°C - 35°C (41°F - 95°F) |
| Weight | 250g/7.1oz |
Connection:
| Connection Methods | Press A Button | LED indicator | BT Name |
|---|---|---|---|
| PS3/PS4 | When you use it for the first time, please use the USB cable to connect to the console. | LED Always On | |
| Android System | “SHARE”+“HOME” | Top LED fast double blink | DUALSHOCK 4 Wireless Controller |
| iOS System | “SHARE”+“HOME” | Top LED fast double blink | DUALSHOCK 4 Wireless Controller |
| PC Windows - Wireless | “SHARE”+“HOME” | Top LED fast double blink | Wireless Controller |
| PC Windows - Wired | Using Micro-USB cable | LED Always On |
How to turn on/off?
The controller has a memory function. Press and hold the Home button for 2 seconds to enter automatic pairing, giving priority to connecting to the last connected device.
If it is not connected to any device within 20 seconds, the controller will shut down.
If you need to pair to a new device, please use the pairing function: press and hold the “SHARE” + “Home” button for 5 seconds, the top LED will flash quickly, and you can see the Bluetooth name of the controller on the device to be connected. Click to connect the controller.
How to fix ps4 Mic not working?
If you find that the microphone does not work when you connect headphones to the controller, please set it up on the PS4 console.
Specific setting path: Settings in PS4 system -> Devices -> Audio Devices -> Output to Headphones -> All Audio
If the problem still occurs, please re-pair the controller: remove all Bluetooth devices in the PS4 system, restart the PS4 Console, use a USB cable to pair the controller with the PS4 console, and set the Audio device to headphones again after pairing is completed.
Sleep mode of the controller
The controller has a sleep function. If you do not press any button within 5 minutes, it will automatically sleep. When you press the “Home” button, the controller and the connected PS4 console will automatically wake up.
Please note that when the controller is low on power, joystick drift, button delay and other problems are prone to occur. Please make sure to keep the controller fully charged.
When the controller is low on power, the top LED will light up/flash red.
How to reset controller?
On the back of the controller, below the L2 trigger, there is an initialization button. You need to insert a small stick with the controller connected/powered on and press the button for more than 8 seconds in order for the controller to initialize.
